Specification

Material: 1.5mm #304 Satin Stainless Steel

Motor:

• 1/4 HP, 7500 rpm, Brush Type, Dual Ball Bearings
• Motor Thermal Protection- Auto Resetting Thermostat turns off at 105°C

Features: Touch Free High Flow Outlet

Warranty:

• 5 Year Warranty
• (3 Years Parts and Labour
• + 2 Years Parts only)

Power Use: 230-240 Vac, 50/60Hz, 2200-2400W

Dimensions: 268mmW x 283mmH x 100mmD

Operating Sound Level: 70db (+/- 3)

Motor Speed (Max Settings): 7,500 RPM

Motor Speed (Min Settings): 7,500 RPM

Air Speed (Max Settings): 24m/s == 53MPH

Air Speed (Min Settings): 24m/s == 53MPH

Heater Element Power: 2200 Watts

Motor Cut-Off Time: 60-sec power cut off, auto reset

Rated Power (Max Settings): 2400 Watts

Rated Power (Min Settings): 2200 Watts

Energy Per Day (Max Settings): 10 Watt-hours (Wh)

Energy Per Day (Min Settings): 9.16 Watt-hours (Wh)

Sensor Type:

• Infrared Automatic, self-adjusting
• Adjustable, standard 18cm ± 2cm

Drying Time: Less than 15 seconds

Carbon Dioxide Emission: 731g Only

IP Rating: IP 21

DP Rating: IPX 1

Heater Element: 2200W @ 240Vac

Heater:

• Auto Resetting Thermostat turns unit off at 87°C
• The thermal fuse cuts the unit off at 141°C

Warm Air: Output:314.5m3/h (185 CFM) Temp: Ambient +20C

Protection: 60-sec power cut off, auto reset

Timing: 2-sec delay turn off after the last read

Case Security: 2 SS theft-resistant hex drive screws (hex key supplied)

Net Weight: 4.5kg
